LineWise has introduced its new TLL-500A Triple Line Lifter for subtransmission applications. The new product is designed to be a low-cost, lightweight solution for supporting three phases of energized conductors between 34.5 kV to 72.5 kV.
The four main components of the TLL-500A are easy to assemble on the jobsite. The steel mast, which contains a turntable that allows it to swivel up to 15 degrees left or right, quickly pins to digger derrick adapters. The heavy-duty steel cross arm includes wear pads for maximum durability. Aluminum extension arms allow adjustment of the polymer insulators in 3-inch increments from a minimum overall span of 7 feet, 4 inches to a maximum span of 16 feet. Insulators can be spaced a minimum of 3 feet, 8 inches apart or a maximum of 8 feet apart.
The TLL-500A can be used in a horizontal or vertical configuration. It supports a maximum load of 500 pounds per position with a maximum side load of 200 pounds per position. An optional Delta configuration allows operators to hang insulators in a downward position from the insulator sliders. Insulator extender attachments can extend insulators to accommodate pole structures with one conductor that is higher than the rest. A static arm attachment is also available to pick the static line at the same time as the conductors.
The TLL-500A comes in a convenient skid container that allows forklift loading from any side and will fit into standard full-size pickup beds.
LineWise is a division of Diversified Products. The company designs, engineers and manufactures a full line of utility products, including line lifters, insulated work platforms, phase lifters, transmission temporary conductor supports and the Buddy Bushing transmission hardware reinforcement system. For more information, contact Diversified Product Development, 1001 Webster Avenue, Waco, Texas 76706, phone 254-757-1177, fax 254-757-1188, or visit the website at www.line-wise.com.
